To install concrete lintels safely and correctly, it is essential that you follow our installation guidelines:

• Ensure the lintel is not damaged
• The lintel should be installed with a minimum end bearing of 150mm
• Ensure the lintel is used in its correct orientation and is fully bedded in a level position on mortar across its length and width
• The masonry below the lintel should be built in accordance with EN 1996-1-1
• Where required in external walls, a flexible damp proof course or cavity tray should be installed in accordance with current building regulations
• If required, rendering of the lintel is not deemed to be detrimental to its performance
• Do not cut into the lintel to form rebates or modify in any way – if in doubt please contact the Superior Fix technical department

Our precast concrete lintels are available in the following dimensions:

100 x 150 (max length 2700mm) £ P.O.A L/M
100 x 215 (max length 3300mm) £ P.O.A L/M
140 x 140 (max length 2700mm) £ P.O.A L/M
140 x 215 (max length 3900mm) £ P.O.A L/M

Please note that all prices are inclusive of VAT. Please ask for a delivery quote when placing an order.
